Android 抽屉式Activity(人们网所用(有图有真相))

热度:11   发布时间:2016-05-01 17:55:46.0
Android 抽屉式Activity(人人网所用(有图有真相))

---------------------------main.xml

<?xml version="1.0" encoding="utf-8"?>
<AbsoluteLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:id="@+id/layout"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent" >

    <FrameLayout
        android:id="@+id/slideout_placeholder"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        android:background="#777777" >

        <ListView
            android:id="@+id/list"
            android:layout_width="fill_parent"
            android:layout_height="fill_parent"
            android:cacheColorHint="#00000000" />
    </FrameLayout>

    <ImageView
        android:id="@+id/slidedout_cover"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        android:scaleType="fitXY" />

</AbsoluteLayout>

------------------------blog.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:id="@+id/inner_content"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:background="@android:color/white" >

    <LinearLayout
        android:id="@+id/linearLayout1"
        android:layout_width="fill_parent"
        android:layout_height="45dip"
        android:background="#bb000000"
        android:gravity="center_vertical"
        android:orientation="horizontal" >

        <Button
            android:id="@+id/sample_button"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_marginRight="10dip"
            android:background="@drawable/right" />

        <TextView
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="I hate working 公子白"
            android:textColor="#ffffff"
            android:textSize="19sp" />
    </LinearLayout>

    <WebView
        xmlns:android="http://schemas.android.com/apk/res/android"
        android:id="@+id/webView1"
        android:layout_width="fill_parent"
        android:layout_height="fill_parent"
        android:layout_marginTop="40dip" />

</RelativeLayout>





------------------------------.主JAVA

package slidre.co.cc;

import android.app.Activity;
import android.content.Context;
import android.content.Intent;
import android.graphics.Bitmap;
import android.graphics.Bitmap.Config;
import android.graphics.Canvas;
import android.os.Bundle;
import android.util.TypedValue;
import android.view.KeyEvent;
import android.view.View;
import android.view.View.OnClickListener;
import android.view.WindowManager;
import android.view.animation.Animation;
import android.view.animation.Animation.AnimationListener;
import android.view.animation.TranslateAnimation;
import android.widget.AdapterView;
import android.widget.AdapterView.OnItemClickListener;
import android.widget.ArrayAdapter;
import android.widget.ImageView;
import android.widget.ListView;
import android.widget.RelativeLayout.LayoutParams;

public class SettingActivity extends
  Activity {

 private ImageView mCover;
 private ListView mList;
 private Animation mStartAnimation;
 private Animation mStopAnimation;
 private static final int DURATION_MS = 400;
 private static Bitmap sCoverBitmap = null;
 String loveyouString[] = new String[] {
   "公子白工作室", "帅哥 帅哥 帅哥 帅哥",
   "帅哥", "美女", "帅哥 帅哥 帅哥",
   "帅哥 帅哥 帅哥 帅哥", "帅哥 帅哥 帅哥",
   "地上的娃娃笑哈哈" };

 // 2个步骤
 // 1. activity-->other activity
 // 2. anim
 // 先切换到另一个activity
 // 再获得之前activity屏幕的快照将它作为一个cover覆盖在下一个屏幕的上面,然后通过动画移动这个cover,让人感觉好像是前一个屏幕的移动。

 public static void prepare(
   Activity activity, int id) {
  if (sCoverBitmap != null) {
   sCoverBitmap.recycle();
  }
  // 用指定大小生成一张透明的32位位图,并用它构建一张canvas画布
  sCoverBitmap = Bitmap
    .createBitmap(
      activity.findViewById(
        id)
        .getWidth(),
      activity.findViewById(
        id)
        .getHeight(),
      Config.ARGB_8888);
  Canvas canvas = new Canvas(
    sCoverBitmap);
  // 将指定的view包括其子view渲染到这种画布上,在这就是上一个activity布局的一个快照,现在这个bitmap上就是上一个activity的快照
  activity.findViewById(id).draw(
    canvas);
 }

 @Override
 public void onCreate(
   Bundle savedInstanceState) {
  super.onCreate(savedInstanceState);
  // 绝对布局最上层覆盖了一个imageview
  setContentView(R.layout.main);
  initAnim();
  mCover = (ImageView) findViewById(R.id.slidedout_cover);
  mCover.setImageBitmap(sCoverBitmap);
  mCover.setOnClickListener(new OnClickListener() {
   @Override
   public void onClick(View v) {
    close();
   }
  });
  mList = (ListView) findViewById(R.id.list);
  mList.setAdapter(new ArrayAdapter<String>(
    SettingActivity.this,
    android.R.layout.simple_list_item_1,
    loveyouString));
  mList.setOnItemClickListener(new OnItemClickListener() {

   @Override
   public void onItemClick(
     AdapterView<?> arg0,
     View arg1,
     int arg2, long arg3) {
    // if (String[0]) {
    //
    // }
    //
    if (arg2 == 1) {
     Intent intent = new Intent(
       SettingActivity.this,
       Gongzibai.class);
     startActivity(intent);
     finish();

    }

    if (arg2==3) {

     Intent intent1 = new Intent(
       SettingActivity.this,
       Gongzibai1.class);
     startActivity(intent1);
     finish();

    }
    close();

   }
  });
  open();
 }

 public void initAnim() {

  // 采用了绝对布局,绝对布局是view的左上角从(0,0)开始
  @SuppressWarnings("deprecation")
  final android.widget.AbsoluteLayout.LayoutParams lp = new android.widget.AbsoluteLayout.LayoutParams(
    LayoutParams.FILL_PARENT,
    LayoutParams.FILL_PARENT,
    0, 0);
  findViewById(
    R.id.slideout_placeholder)
    .setLayoutParams(lp);

  // 屏幕的宽度
  int displayWidth = ((WindowManager) getSystemService(Context.WINDOW_SERVICE))
    .getDefaultDisplay()
    .getWidth();
  // 右边的位移量,60dp转换成px
  int sWidth = (int) TypedValue
    .applyDimension(
      TypedValue.COMPLEX_UNIT_DIP,
      60,
      getResources()
        .getDisplayMetrics());
  // 将快照向右移动的偏移量
  final int shift = displayWidth
    - sWidth;

  // 向右移动的位移动画向右移动shift距离,y方向不变
  mStartAnimation = new TranslateAnimation(
    TranslateAnimation.ABSOLUTE,
    0,
    TranslateAnimation.ABSOLUTE,
    shift,
    TranslateAnimation.ABSOLUTE,
    0,
    TranslateAnimation.ABSOLUTE,
    0);

  // 回退时的位移动画
  mStopAnimation = new TranslateAnimation(
    TranslateAnimation.ABSOLUTE,
    0,
    TranslateAnimation.ABSOLUTE,
    -shift,
    TranslateAnimation.ABSOLUTE,
    0,
    TranslateAnimation.ABSOLUTE,
    0);
  // 持续时间
  mStartAnimation
    .setDuration(DURATION_MS);
  // 动画完成时停留在结束位置
  mStartAnimation
    .setFillAfter(true);
  mStartAnimation
    .setAnimationListener(new AnimationListener() {

     @Override
     public void onAnimationStart(
       Animation animation) {
     }

     @Override
     public void onAnimationRepeat(
       Animation animation) {
     }

     @Override
     public void onAnimationEnd(
       Animation animation) {
      // 动画结束时回调
      // 将imageview固定在位移后的位置
      mCover.setAnimation(null);
      @SuppressWarnings("deprecation")
      final android.widget.AbsoluteLayout.LayoutParams lp = new android.widget.AbsoluteLayout.LayoutParams(
        LayoutParams.FILL_PARENT,
        LayoutParams.FILL_PARENT,
        shift,
        0);
      mCover.setLayoutParams(lp);
     }
    });

  mStopAnimation
    .setDuration(DURATION_MS);
  mStopAnimation
    .setFillAfter(true);
  mStopAnimation
    .setAnimationListener(new AnimationListener() {

     @Override
     public void onAnimationStart(
       Animation animation) {
     }

     @Override
     public void onAnimationRepeat(
       Animation animation) {
     }

     @Override
     public void onAnimationEnd(
       Animation animation) {
      finish();
      overridePendingTransition(
        0, 0);
     }
    });

 }

 public void open() {
  mCover.startAnimation(mStartAnimation);
 }

 public void close() {
  mCover.startAnimation(mStopAnimation);
 }

 @Override
 public boolean onKeyDown(
   int keyCode, KeyEvent event) {
  // 摁返回键时也要触发动画
  if (keyCode == KeyEvent.KEYCODE_BACK) {
   close();
   return true;
  }
  return super.onKeyDown(keyCode,
    event);
 }
}

-----------------------项目.AVTIVITY

package slidre.co.cc;

import cn.mapplayer.engine.MiidiCredit;
import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.view.View;
import android.view.View.OnClickListener;

public class SliderActivity extends
  Activity {
 @Override
 protected void onCreate(
   Bundle savedInstanceState) {
  super.onCreate(savedInstanceState);


  setContentView(R.layout.sample);
  findViewById(R.id.sample_button)
    .setOnClickListener(
      new OnClickListener() {
       @Override
       public void onClick(
         View v) {
        SettingActivity
          .prepare(
            SliderActivity.this,
            R.id.inner_content);
        startActivity(new Intent(
          SliderActivity.this,
          SettingActivity.class));
        overridePendingTransition(
          0,
          0);
       }
      });
 }
}





------------------加上权限ACTIVITY 以及网络
