<FrameLayout        android:layout_width="match_parent"        android:layout_height="match_parent" >        <com.example.empty.ChartView            android:id="@+id/chart"            android:layout_width="wrap_content"            android:layout_height="wrap_content"            android:layout_gravity="center" />    </FrameLayout>

package com.example.empty;import java.util.ArrayList;import java.util.List;import android.content.Context;import android.graphics.Canvas;import android.graphics.Paint;import android.graphics.Point;import android.util.AttributeSet;import android.view.View;public class ChartView extends View{    private List mPointList = new ArrayList();    private int mPointY = 0;    private Paint mPoint = new Paint();   //画笔        public ChartView(Context context, AttributeSet attrs) {        // TODO Auto-generated constructor stub        this(context, attrs, 0);    }        public ChartView(Context context, AttributeSet attrs, int defStyleAttr) {        super(context, attrs, defStyleAttr);        // TODO Auto-generated constructor stub        //初始化画笔        mPoint.setColor(getContext().getResources().getColor(                R.color.color_tiny_blue));        mPoint.setStrokeWidth(2.0f);        mPoint.setAntiAlias(true);    }        @Override    protected void onDraw(Canvas paramCanvas) {        super.onDraw(paramCanvas);        //mPointY = (int) (Math.random() * 100);        if (mPointList.size() >= 2) {            for (int k = 0; k < -1 + mPointList.size(); k++) {                paramCanvas.drawLine(((Point) mPointList.get(k)).x,                        ((Point) mPointList.get(k)).y,                        ((Point) mPointList.get(k + 1)).x,                        ((Point) mPointList.get(k + 1)).y, mPoint);            }        }        Point localPoint1 = new Point(getWidth(), mPointY);        int i = mPointList.size();        int j = 0;        if (i > 101) {                    //最多绘制100个点，多余的出栈            mPointList.remove(0);            while (j < 100) {                Point localPoint3 = (Point) mPointList.get(j);                localPoint3.x = (-7 + localPoint3.x);                j++;            }            mPointList.add(localPoint1);            return;        }                while (j < mPointList.size()) {    //每新产生使前面的每一个点左移7            Point localPoint2 = (Point) mPointList.get(j);            localPoint2.x = (-7 + localPoint2.x);            j++;        }        mPointList.add(localPoint1);    }    public final void ClearList() {        mPointList.clear();    }    public final void AddPointToList(int paramInt) {        mPointY = paramInt;        invalidate();//重绘    }        public void stop(){        mPointList.clear();        invalidate();    }}

mChartView = (ChartView)findViewById(R.id.chart);        Timer timer = new Timer();        TimerTask task = new TimerTask() {            @Override            public void run() {                Message msg = new Message();                mHandler.sendMessage(msg);            }        };        timer.schedule(task,1,300);                            private Handler mHandler = new Handler() {        @Override        public void dispatchMessage(Message msg) {            mChartView.AddPointToList((int) (Math.random() * 100));        }    };
