vue中使用骨架 vue-skeleton-webpack-plugin

1、调试的时候可以在浏览器中修改network为slow 3g这样加载的时间就比较长

一、安装webpack插件

npm install vue-skeleton-webpack-plugin

二、创建模板文件

如果不同的路由界面显示不同的模板可以创建过个模板文件，我在src文件夹下面创建了三个文件

Skeleton1.vue

</template><script>
export default {
    name: 'skeleton'
};
</script><style scoped>
.skeleton-header {
    height: 152px;background: grey;margin-top: 60px;width: 152px;margin: 60px auto;
}
.skeleton-block {
    display: flex;flex-direction: column;padding-top: 8px;
}
</style>

Skeleton2.vue

</template><script>
export default {
    name: 'skeleton'
};
</script><style scoped>
.skeleton-header {
    height: 152px;background: grey;margin-top: 60px;width: 152px;margin: 60px auto;
}
.skeleton-block {
    display: flex;flex-direction: column;padding-top: 8px;
}
</style>

entry-skeleton.js

import Vue from 'vue'
import Skeleton1 from './Skeleton1'
import Skeleton2 from './Skeleton2'export default new Vue({
    components: {
    Skeleton1,Skeleton2},template: `<div><skeleton1 id="skeleton1" style="display:none"/><skeleton2 id="skeleton2" style="display:none"/></div>`
})

三、在build文件中创建webpack.skeleton.conf.js文件

'use strict';const path = require('path')
const merge = require('webpack-merge')
const baseWebpackConfig = require('./webpack.base.conf')
const nodeExternals = require('webpack-node-externals')
const utils = require('./utils')
const config = require('../config')
const isProduction = process.env.NODE_ENV === 'production'
const sourceMapEnabled = isProduction? config.build.productionSourceMap: config.dev.cssSourceMapfunction resolve(dir) {
    return path.join(__dirname, dir)
}let skeletonWebpackConfig = merge(baseWebpackConfig, {
    target: 'node',devtool: false,entry: {
    // 刚定义的模板文件入口app: resolve('../src/entry-skeleton.js')},output: Object.assign({
    }, baseWebpackConfig.output, {
    libraryTarget: 'commonjs2'}),externals: nodeExternals({
    whitelist: /\.css$/}),plugins: []
})// important: enable extract-text-webpack-plugin
skeletonWebpackConfig.module.rules[0].options.loaders = utils.cssLoaders({
    sourceMap: sourceMapEnabled,extract: true
}),module.exports = skeletonWebpackConfig

四、然后我们修改webpack.dev.conf.js在开发环境测试，如果需要上线，webpack.prod.conf.js也需要做相同的配置

...
// 1. 导入插件
const SkeletonWebpackPlugin = require('vue-skeleton-webpack-plugin')
...
// 2. 配置插件
plugins: [...new SkeletonWebpackPlugin({
    // 导入我定义的配置文件webpackConfig: require('./webpack.skeleton.conf'),quiet: true,minimize: true,router: {
    mode: 'hash',routes: [// 不同路由界面配置不同的模板{
    path: '/',skeletonId: 'skeleton1'},{
    path: '/cart',skeletonId: 'skeleton2'}]}})...

下面的图片是目录结构和路由的配置：
