Flutter 浅析之 自定义view (自定义图形 绘制drawImage 加载本地图片 ui.Image的使用) 四

技术无止境，只怕不学习啊，Flutter 我们开始吧

绘制drawImage的时候遇到一个问题获取要绘制的图片，查询的一些资料找出来一个方法可以回去本地图片 ，因为绘制的时候Image对象必须使用ui.Image

 /// 通过assets路径，获取资源图片Future<ui.Image> load(String asset) async {
    ByteData data = await rootBundle.load(asset);ui.Codec codec = await ui.instantiateImageCodec(data.buffer.asUint8List());ui.FrameInfo fi = await codec.getNextFrame();return fi.image;}

使用的时候怎么都回去不到图片，分析这个函数中使用了async 和await 在Dart中他们是异步执行，问题就在这里了，异步回去图片，那应该在哪里初始化绘制的时候才能回去到图片那？
答案是在页面初始化的时候获取图片然后把ui.Image传给自定义的view,初始化函数initState。

@overridevoid initState() {
    super.initState();/*** 注意在初始化函数里面加加载图片* build 函数中把图片传给TestPainter对象*/load("images/timg.jpg").then((i) {
    setState(() {
    _image = i;});});}

传入值：

@overrideWidget build(BuildContext context) {
    // TODO: implement buildvar paint = CustomPaint(size: Size(300,300),painter: TestPainter(_image),);return Scaffold(appBar: AppBar(title: Text( "Canvas的用法"),),body: Container(child: paint,),);}

整体的代码如下：

import 'dart:ui';
import 'dart:ui' as ui;import 'package:flutter/material.dart';
import 'package:flutter/services.dart';
import 'package:flutterapptest/NewRoute.dart';
import 'TestPainter.dart';void main() {
    runApp(MyApp());
}class MyApp extends StatelessWidget {
    // This widget is the root of your application.@overrideWidget build(BuildContext context) {
    return MaterialApp(title: 'Flutter Demo',theme: ThemeData(primarySwatch: Colors.red, // 风格颜色visualDensity: VisualDensity.adaptivePlatformDensity,),routes:{
    "new_page":(context) => NewRoute(),},home: MyHomePage(title: '测试项目'),);}
}class MyHomePage extends StatefulWidget {
    MyHomePage({
    Key key, this.title}) : super(key: key);final String title;@override_MyHomePageState createState() => _MyHomePageState();
}class _MyHomePageState extends State<MyHomePage> {
    ui.Image _image;@overridevoid initState() {
    super.initState();/*** 注意在初始化函数里面加加载图片* build 函数中把图片传给TestPainter对象*/load("images/timg.jpg").then((i) {
    setState(() {
    _image = i;});});}@overrideWidget build(BuildContext context) {
    // TODO: implement buildvar paint = CustomPaint(size: Size(300,300),painter: TestPainter(_image),);return Scaffold(appBar: AppBar(title: Text( "Canvas的用法"),),body: Container(child: paint,),);}/// 通过assets路径，获取资源图片Future<ui.Image> load(String asset) async {
    ByteData data = await rootBundle.load(asset);ui.Codec codec = await ui.instantiateImageCodec(data.buffer.asUint8List());ui.FrameInfo fi = await codec.getNextFrame();return fi.image;}}

import 'dart:ui' as ui;
import 'dart:ui';
import 'package:flutter/material.dart';class TestPainter extends CustomPainter {
    Paint _paint = new Paint()..color = Colors.blueAccent // 画笔颜色..strokeCap = StrokeCap.round //画笔笔触类型..isAntiAlias = true //是否启动抗锯齿..strokeWidth = 6.0 //画笔的宽度..style = PaintingStyle.stroke // 样式..blendMode = BlendMode.colorDodge; // 模式ui.Image _image;TestPainter(this._image) {
    this._image = _image;}@overridevoid paint(Canvas canvas, Size size) {
    // TODO: implement paintif (_image != null) {
    canvas.drawImage(_image, Offset(0, 0), _paint);
// canvas.drawImageRect(_image, Offset(0.0, 0.0) & Size(_image.width.toDouble(), _image.height.toDouble()), Offset(0.0, 0.0) & Size(200, 200), _paint);}}@overridebool shouldRepaint(CustomPainter oldDelegate) {
    // TODO: implement shouldRepaint///是否需要重绘return false;}
}

绘制图片时候遇到的问题记录一下，搜了还就没有找到相关的问题。加油吧童鞋们！
