大数据：Spark Standalone 集群调度（三）多Master节点的可用性

In order to enable this recovery mode, you can set SPARK_DAEMON_JAVA_OPTS in spark-env using this configuration:

-Dspark.deploy.recoveryMode=ZOOKEEPER

override def isLeader() {synchronized {// could have lost leadership by now.if (!leaderLatch.hasLeadership) {return}logInfo("We have gained leadership")updateLeadershipStatus(true)}}override def notLeader() {synchronized {// could have gained leadership by now.if (leaderLatch.hasLeadership) {return}logInfo("We have lost leadership")updateLeadershipStatus(false)}}

  private def updateLeadershipStatus(isLeader: Boolean) {if (isLeader && status == LeadershipStatus.NOT_LEADER) {status = LeadershipStatus.LEADERmasterInstance.electedLeader()} else if (!isLeader && status == LeadershipStatus.LEADER) {status = LeadershipStatus.NOT_LEADERmasterInstance.revokedLeadership()}}

  override def electedLeader() {self.send(ElectedLeader)}override def revokedLeadership() {self.send(RevokedLeadership)}

ls /spark/leader_election
[_c_6b494d00-cf91-4d69-8828-942377bafdf1-latch-0000000217, _c_c1f4c10f-9479-4a55-b660-0497c0b54f89-latch-0000000218]

2.3 StandBy Master 节点的恢复

    case ElectedLeader =>val (storedApps, storedDrivers, storedWorkers) = persistenceEngine.readPersistedData(rpcEnv)state = if (storedApps.isEmpty && storedDrivers.isEmpty && storedWorkers.isEmpty) {RecoveryState.ALIVE} else {RecoveryState.RECOVERING}logInfo("I have been elected leader! New state: " + state)if (state == RecoveryState.RECOVERING) {beginRecovery(storedApps, storedDrivers, storedWorkers)recoveryCompletionTask = forwardMessageThread.schedule(new Runnable {override def run(): Unit = Utils.tryLogNonFatalError {self.send(CompleteRecovery)}}, WORKER_TIMEOUT_MS, TimeUnit.MILLISECONDS)}

2.3.1 获取具体的信息

 ls /spark/master_status
[worker_worker-20170329184022-192.168.121.101-55109, worker_worker-20170330035822-192.168.121.102-41307]

private def beginRecovery(storedApps: Seq[ApplicationInfo], storedDrivers: Seq[DriverInfo],storedWorkers: Seq[WorkerInfo]) {for (app <- storedApps) {logInfo("Trying to recover app: " + app.id)try {registerApplication(app)app.state = ApplicationState.UNKNOWNapp.driver.send(MasterChanged(self, masterWebUiUrl))} catch {case e: Exception => logInfo("App " + app.id + " had exception on reconnect")}}for (driver <- storedDrivers) {// Here we just read in the list of drivers. Any drivers associated with now-lost workers// will be re-launched when we detect that the worker is missing.drivers += driver}for (worker <- storedWorkers) {logInfo("Trying to recover worker: " + worker.id)try {registerWorker(worker)worker.state = WorkerState.UNKNOWNworker.endpoint.send(MasterChanged(self, masterWebUiUrl))} catch {case e: Exception => logInfo("Worker " + worker.id + " had exception on reconnect")}}}

2.3.2.1 恢复Application

  private def completeRecovery() {// Ensure "only-once" recovery semantics using a short synchronization period.if (state != RecoveryState.RECOVERING) { return }state = RecoveryState.COMPLETING_RECOVERY// Kill off any workers and apps that didn't respond to us.workers.filter(_.state == WorkerState.UNKNOWN).foreach(removeWorker)apps.filter(_.state == ApplicationState.UNKNOWN).foreach(finishApplication)// Reschedule drivers which were not claimed by any workersdrivers.filter(_.worker.isEmpty).foreach { d =>logWarning(s"Driver ${d.id} was not found after master recovery")if (d.desc.supervise) {logWarning(s"Re-launching ${d.id}")relaunchDriver(d)} else {removeDriver(d.id, DriverState.ERROR, None)logWarning(s"Did not re-launch ${d.id} because it was not supervised")}}state = RecoveryState.ALIVEschedule()logInfo("Recovery complete - resuming operations!")}

2.3.2.2 恢复Worker

recoveryCompletionTask = forwardMessageThread.schedule(new Runnable {override def run(): Unit = Utils.tryLogNonFatalError {self.send(CompleteRecovery)}}, WORKER_TIMEOUT_MS, TimeUnit.MILLISECONDS)

RecoveryState.ALIVE
RecoveryState.RECOVERING
RecoveryState.COMPLETING_RECOVERY
RecoveryState.STANDBY

--master spark://raintungmaster:7077,raintungslave1:7077
