原理：
1.气泡自由移动，就是随机的在气泡的四个方向上（上下左右）移动一个距离。
2.漩涡向内收缩，其实就是使用圆的极坐标方程x = R*cos(theta) + centerX; y = R*sin(theta) + centerY;让R和theta都成为变量。
废话不多说直接上代码：
</pre><pre name="code" class="java">package com.stevens.ui.view;import android.content.Context;import android.graphics.Canvas;import android.graphics.Color;import android.graphics.LinearGradient;import android.graphics.Paint;import android.graphics.Rect;import android.graphics.Shader;import android.os.SystemClock;import android.util.AttributeSet;import android.util.Log;import android.view.KeyEvent;import android.view.MotionEvent;import android.view.View;import java.util.ArrayList;import java.util.Random;public class BubbleView extends View implements Runnable { private static final String TAG = "BubbleView"; private static final int NORTH = 0; private static final int SOUTH = 1; private static final int EAST = 2; private static final int WEST = 3; private static final int NORTH_WEST = 4; private static final int NORTH_EAST = 5; private static final int SOUTH_WEST = 6; private static final int SOUTH_EAST = 7; private boolean isInitBubble = false; private static final int count = 10; private int height, width; private Rect viewRect; Shader mShasder; private Paint paint; private boolean isRunning = true; private Canvas canvas; private ArrayList<Circle> bubbles = new ArrayList<Circle>(); private Random rand = new Random(); private boolean isChangeRunning = false; private int frequency = 0; public BubbleView(Context context, AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr); init(); } public BubbleView(Context context, AttributeSet attrs) { super(context, attrs); init(); } public BubbleView(Context context) { super(context); init(); } @Override public void run() { while (isRunning) { SystemClock.sleep(10); this.postInvalidate(); } } @Override public boolean onKeyDown(int keyCode, KeyEvent event) { switch (keyCode) { case KeyEvent.KEYCODE_DPAD_CENTER: break; case KeyEvent.KEYCODE_BACK: isRunning = false; break; case KeyEvent.KEYCODE_HOME: isRunning = false; default: break; } return super.onKeyDown(keyCode, event); } @Override public boolean onTouchEvent(MotionEvent event) { // TODO Auto-generated method stub switch (event.getAction()) { case MotionEvent.ACTION_DOWN: if (!isChangeRunning) { isChangeRunning = true; } else { isChangeRunning = false; } break; default: break; } return super.onTouchEvent(event); } @Override protected void onDraw(Canvas canvas) { if (!isInitBubble) { height = this.getHeight(); width = this.getWidth(); viewRect = new Rect(0, 0, width, height); mShasder = new LinearGradient(0, 0, 0, height, new int[] { Color.GREEN, Color.BLUE }, null, Shader.TileMode.CLAMP); isInitBubble = true; for (int i = 0; i < count; i++) { bubbles.add(new Circle(rand.nextInt(width), rand.nextInt(height), rand.nextInt(30) + 20, rand.nextInt(60) + 40)); } } paint.reset(); paint.setShader(mShasder); canvas.drawColor(Color.BLACK); canvas.drawRect(viewRect, paint); if (frequency % 5 == 0) { for (Circle c : bubbles) { if (isChangeRunning) { c.runBubble(); } else { c.increase(); } } } for (Circle c : bubbles) { c.draw(canvas, paint); } frequency++; super.onDraw(canvas); } private void init() { paint = new Paint(); this.setFocusable(true); new Thread(this).start(); } private class CircleCenterPoint { private float x; private float y; public CircleCenterPoint(float x, float y) { this.x = x; this.y = y; } public float getX() { return x; } public void setX(float x) { this.x = x; } public float getY() { return y; } public void setY(float y) { this.y = y; } public boolean isOutOfView(float r) { boolean isOutView = false; if (x > width - r || x < r || y > height - r || y <= r) { isOutView = true; } return isOutView; } public boolean isInCenterView(float r, float centerViewR) { boolean isOutView = false; if (x > width / 2 - centerViewR && x < width / 2 + centerViewR && y > height / 2 - centerViewR && y <= height / 2 + centerViewR) { isOutView = true; } return isOutView; } } private class Circle { private CircleCenterPoint center; private float r; private int a; private int aMax; private double distance; private double minDistance; private int type = rand.nextInt(100); private int count = 0; private double delta = 0.1f; private double theta = 0; private boolean isInitDistance = false; private double delta2 = 0.1f; boolean isShouldDisapear = false; public Circle(float x, float y, float r, int a) { center = new CircleCenterPoint(x, y); this.r = r; this.a = a; minDistance = rand.nextInt(100); } public void runBubble() { if (!isInitDistance) { isInitDistance = true; float x = center.getX() - width / 2; float y = center.getY() - height / 2; distance = Math.sqrt((double) (x * x + y * y)); if (x > 0) { theta = Math.atan(y / x); } else { theta = Math.atan(y / x) + Math.PI; } } theta = theta + 0.1; distance = getDistance(distance); center.setY((float) (distance * Math.sin(theta)) + height / 2); center.setX((float) (distance * Math.cos(theta)) + width / 2); } public void increase() { if (isInitDistance) { delta = 0.1f; isInitDistance = false; } changeCenterPoint(center, type); if (center.isOutOfView(r) || center.isInCenterView(r, 100f)) { isShouldDisapear = true; } } public void draw(Canvas canvas, Paint paint) { count++; if (count % ((type + 8) * 10) == 0) { type = rand.nextInt(100); } if (isShouldDisapear) { a--; if (a <= 0) { isShouldDisapear = false; center.setX(rand.nextInt(width)); center.setY(rand.nextInt(height)); r = rand.nextInt(30) + 20; aMax = rand.nextInt(60) + 40; } } else { if (a <= aMax) { a++; } else { aMax = 0; } } paint.reset(); paint.setColor(Color.WHITE); paint.setAlpha(a); canvas.drawCircle(center.getX(), center.getY(), r, paint); } private double getDistance(double distance) { double result = distance; delta = delta + 0.1; result = result - delta * delta; if (result < minDistance) { result = minDistance; } return result; } } private void changeCenterPoint(CircleCenterPoint center, int type) { switch (type % 8) { case NORTH: center.setX(center.getX()); center.setY(center.getY() - rand.nextInt(4)); break; case SOUTH: center.setX(center.getX()); center.setY(center.getY() + rand.nextInt(4)); break; case EAST: center.setX(center.getX() + rand.nextInt(4)); center.setY(center.getY()); break; case WEST: center.setX(center.getX() - rand.nextInt(4)); center.setY(center.getY()); break; case NORTH_WEST: center.setX(center.getX() - rand.nextInt(4)); center.setY(center.getY() - rand.nextInt(4)); break; case NORTH_EAST: center.setX(center.getX() + rand.nextInt(4)); center.setY(center.getY() - rand.nextInt(4)); break; case SOUTH_WEST: center.setX(center.getX() + rand.nextInt(4)); center.setY(center.getY() + rand.nextInt(4)); break; case SOUTH_EAST: center.setX(center.getX() - rand.nextInt(4)); center.setY(center.getY() + rand.nextInt(4)); break; } }}
注意的问题：
1.这里的theta时候弧度，而非角度(高中的数学都还给数据老师了，很久以后才想明白^-^)。
2.由于直接使用随机值来计算气泡的下一个坐标，会发现气泡总是在一个位置停留很久，不是特别自然，这里让在跑随机在一个方向上多移动一会儿。
